Thru Hull Xenon (HID)


  • High performance 35W Xenon HID Light
  • Heavy duty marine bronze housing
  • Thick Borofloat glass lens
  • Remote ballast HID bulb can be changed from inside the vessel.
  • White light
35W Xenon - White Light, 12V DC
Part Number:
2LT 980 755-001
USA: 980755001

35W Xenon - White Light, 24V DC
Part Number:
2LT 980 755-101
USA: 980755101



Lens Material
Borofloat glass. 9.5mm (0.38”)

Housing Material
Marine bronze 80mm (3.15") x 128mm (5.04")

Light Source
35W HID Xenon

Light Output
3000+ Lumens

Operating Voltage
12V DC or 24V DC

Power Consumption
<42W ( < 3.5A @ 12V  / <1.75 @ 24V)

Degree of Protection
IP 67 - Completely sealed

Weight
2.2 kgs / 5.9 lbs

Installation type
Thru Hull. 60mm (2.36") cut out hole
Ballast has 425mm (17") cable
This cable can not be spliced into.

Recommended Positioning
At least 6” (152mm) below waterline
between 3-6ft (1-2 meters) apart.

Suitable hull materials
GRP / fiberglass / wood

Approvals
CE, ABS, Ignition Protection

Manufactured in
USA

Outline

Light diagram:
