2 NM Port Lamp Series: Classic Line

BSH approved Classic Line navigation lamps offer durable and timeless stainless steel jackets. The lamps are saltwater resistant and non-magnetic, with a centrally located connector for easy bulb changes. Classic Line lamps are removable when the universal mount is used.

Part Number:
2LT 002 386-041
USA: 002 386-041

For direct mounting

Part Number:
2LT 002 386-061
USA: 002 386-061

Specifications

Material Description

Polished stainless steel jacket. UV and impact resistant housing and lens.

Bulb

Pre-fitted long-life bulb, 12 V, socket BAY 15d
(2LT 002 386-001 to -061): 12 V / 25 W
(2LT 002 386-021): 12 V / >10 W
(2LT 002 386-401 to -441):
12 V / 25 W / 18 cd

Installation

Screw-connection, 2-pole

Protective System

Dust-proof and splash-proof according to IP 55 (DIN 40050), Vented to prevent water condensation

Mounting

(2LT 002 386-001 to -041 and 2LT 002 386-401 to -441) with insert type bracket on all suitable attachment surfaces
(2LT 002 386-051 to -061) for direct attachment to surfaces running perpendicular and parallel to the midship plane. Suitable screws: M5

Minimum visible Distance

2 NM
