2 NM Port Lamp Series: 2984

BSH approved navigation lamp. Anti-magnetic and saltwater proof. Housing 'snaps' to base without screws. A hanging bulb and contacts in the upper area of each lamp prevents corrosion of the contacts.

Black Housing

Part Number:
2LT 002 984-331
USA: 002 984-331
AUS: 2854
NZ: 2854

White Housing

Part Number:
2LT 002 984-381
USA: 002 984-381
AUS: 2854W
NZ: 2854W

Specifications

Material Description

Shock proof, sturdy plastic light housing and base plate, UV resistant

Bulb

12V / 10W resp. 25W, socket BAY 15d included

Installation

Combined screw-flat-plug connection 6.3 mm

Protective System

According to IP 55 (DIN 40050)

Mounting

Direct attachment, with bolts or self-tapping screws, 5 mm. With universal mount 8HG 122 452-001 to all attachment surfaces, with rail mount 8HG 003 141-001 or attachment base 8HG 005 798-001/011

Minimum visible Distance

2 NM (1 NM Scandinavia)

Cable Entry

through base plate with cable grommet
