1 NM Port Lamp Series: 3562

Compact and proven navigation lamp for yachts and powerboats.
Saltwater proof and non-magnetic, 3562 series lamps feature a 'snap-lock' housing allowing bulbs to be changed without tools.

Black Housing

Part Number:
2LT 003 562-031
USA: 003 562-035
AUS: 2843
NZ: 2843

White Housing

Part Number:
2LT 003 562-131
USA: 003 562-135
AUS: 2843W
NZ: 2843W

Specifications

Material Description

UV and impact resistant plastic housing and lens

Bulb

12V / 10W SV8.5 included

Installation

Vertical surface mount. Mounting base available

Protective System

IP 54

Minimum visible Distance

1 NM

Cable Entry

Through base plate with rubber grommet

Approvals
IMO COLREG, USCG, ABYC A-16, RINA(I)
