Masthead / Deck Floodlight Combination Lamp Series: 8504

Deck Floodlight and Masthead Lamp combined in one robust housing.
Suitable for vessels up to 20m in length.

Features:
- Masthead lamp 2LT 002 984-30
- Hella 'Free Form' reflector technology
- Flexible mounting arms for mounting on a variety of mast profiles
- Illuminates large areas of deck or superstructure
- Glass lens bonded with reflector to be dust and moisture resistant
- Covered bulbs for moisture protection
- All metal parts are stainless steel
- Black or White fibre reinforced housing

Black Housing

Part Number:
2LT 998 504-001
USA: 998 504-001

White Housing

Part Number:
2LT 998 504-011
USA: 998 504-011

Specifications

Material Description

UV and impact resistant plastic housing

Bulb

12V / 10W BAY15d and 12V / 55W H3 bulbs included

Installation

Navigation lamp and Deck Floodlight require separate wiring
Housing arms flex to fit around mast profile

Protective System

IP X4

Max. Output

Deck lamp 12V / 55W or 24V / 70W

Minimum visible Distance

3 NM
