2 NM Masthead Lamp Series: 3562

Compact and proven navigation lamp for yachts and powerboats.
Saltwater proof and non-magnetic, 3562 series lamps feature a 'snap-lock' housing allowing bulbs to be changed without tools.

Black Housing

Part Number:
2LT 003 562-001
USA: 003 562-005
AUS: 2840
NZ: 2840

White Housing

Part Number:
2LT 003 562-101
USA: 003 562-105
AUS: 2840W
NZ: 2840W

Specifications

Material Description

UV and impact resistant plastic housing and lens

Bulb

12V / 10W SV8.5 included

Installation

Vertical surface mount. Mounting base available

Protective System

IP 54

Minimum visible Distance

2 NM

Cable Entry

Through base plate with rubber grommet

Approvals
IMO COLREG, USCG, ABYC A-16, RINA(I)
