Material:
Stainless Steel or
Anodized Aluminum /
Stainless Steel*

Mounting Method:
Screw Mount or
Spring Clips*

Flange Diameter:
3.5" / 3.15"*

Depth:
1.1" / 1.2"*

Suitable Environments:
  Dry,  Damp,  Wet

Emitting Angles:
Flood



Input:
6 to 30VDC

Power:
1.5W / 3W**

Protection:
Reverse Polarity, Transient



Architectural
Industrial
Marine



*spring clip version
**high power version

SMART
No external drivers required. i2Systems SmartDriver technology inside every fixture. Retrofit compatible.

VERSATILE
Connects directly to 12/24V DC systems. Light output remains continuous over the entire 6 to 30V DC range.

EFFICIENT
Only 1.5 Watts per fixture. 50,000 hour operating life.

BRIGHT
Comparable light distribution and output to conventional sources. Produces even light, no LED dots or hot spots.

COOL
Advanced thermal technology and highly efficient design means cool to the touch operation.

STYLISH
5 finishes available. Patent pending PositiveLock* system makes interchanging faceplates effortless. Provides excellent shock and vibration resistance.
*available for screw mounted fixtures only.

UNIQUE
9 LED Color options including Warm White.



----------------------------------------------------------------------------------



IDEAL FOR:
• General Illumination
• Under counter lighting
• Direct retrofit for halogen based applications

0 TO 100% DIGITAL DIMMING
With a single expansion module, dim up to 18 fixtures of any color.



Screw Mount (with Positive Lock)

APL - (X) L - SDI - (Y) 1



LED Color (Y):
 1 White
 2 Warm White
 3 Green
 4 Blue
 5 Royal Blue
 6 Cyan
 7 Red
 8 Red-Orange
 9 Amber





1 Polished Chrome
2 Polished Gold
3 Powder Coated White
4 Brushed Nickel
5 Powder Coated Off-White



Power Selection (Y):
L Low Power
H High Power
